Under Over Voltage Single Phase Protection Relay 110VAC 220VAC 240VAC 250VAC

Name: Under Over Voltage Single Phase Protection Relay 110VAC 220VAC 240VAC 250VAC
Brand: GINRI
Price: 1 USD

Under Over Voltage Single Phase Protection Relay 110VAC 220VAC 240VAC 250VAC Manufactures

Brand Name : GINRI

Model Number : SVR-220

Certification : CE

Place of Origin : China

MOQ : 50Pcs

Payment Terms : L/C, T/T, Western Union,Paypal

Supply Ability : 20000Pcs per month

Delivery Time : within 7 days

Packaging Details : Voltage relay is standard seaworthy package,1pcs individual box or 5pcs in a middle box, 200pcs per carton. Base quotation is blank package. OEM design is acceptable.

Voltage Rnage : 187-253 for SVR-220

Output Contact : 1CO

Measuring Circuit : L,N

Function : over under voltage

Contact Now

Single Phase Under Over Voltage Relay SVR-220 Voltage Protect Monitor Relays 110VAC,220VAC,240VAC 250VAC

What is over under voltage relay?

The state stipulates that the single-phase 220V power supply error shall not exceed 10% of the positive and negative of 220V, that is, when 220V is higher than 242V, it is called overvoltage; below 198V, it is called undervoltage.

In the single-phase 220V power consumption, 220V surges to 380V or 440V ultra-high voltage, called over-voltage; when the grid voltage is suddenly over-voltage, over-voltage and under-voltage, the device that can automatically and automatically cut off the power supply is called overvoltage, Undervoltage protector

♦ Features

-- Single-phase monitoring of over- and undervoltage

-- Powered by the measuring circuit

-- 1 C/O contacts

-- 3 LEDs for status indication

♦ Protective Functions

-- Overvoltage

-- Undervoltage

♦ Typical Applications

• Pumps • Fans

• Blowers • Motors

• Compressors

♦ Approvals

• CE • CCC

♦ Technical data

Type

SVR-220

Measuring circuit

L,N

Rated voltage

110VAC,220VAC ,440VAC

240VAV,250VAC,50/60Hz

Monitoring functions

overvolatege, undervoltage

Voltage setting range

Type suffix	Undervoltage	Overvolatege
blank	+15%	-15%
A	+10%	-10%
B	+12.5%	-10%
C	+15%	-12.5%
T	customized

Indicators

overvolatege, undervoltage, and normal

Output contacts

1 C/O

Contact capacity

3A ,250VAC

Dimensions (H x W x D)

68×30×76mm

Mounting

DIN rail

Under Over Voltage Single Phase Protection Relay 110VAC 220VAC 240VAC 250VAC
